·High-quality material, soft and flexible;
·Highly impact-resistant, with a burst pressure three times the operating pressure;
·Lightweight for easy transportation and handling;
·UV-resistant material ensures a lifespan of over 10 years;
·Custom lengths and colors available.
Detailed Description and Specifications
PVC flat hose is used for industrial water supply and agricultural irrigation. Due to its high strength, PVC is suitable for a variety of high-pressure irrigation applications.
PVC flat hose is not only suitable for agricultural irrigation, but also for lawn and garden irrigation. Its higher pressure allows it to provide a stable water source over longer distances.
PVC is also lightweight, making it easier to work with and carry, and simpler to operate.
PVC CANVAS FLAT HOSE
Polymer coating is resistant to freezing and aging: it has good resistance to acid and alkali, and better compression and explosion resistance. Soft high-density weaving, sturdy and tear resistant: sturdy and durable, tear resistant, even if pulled hard with both hands, it cannot be torn apart
| Size(inch) | Inner Diameter (mm) | Meters roll (m) | Pressure(B.P bar) |
| 2' | 50 | 100 | 9bar |
| 2.5' | 63 | 100 | 9bar |
| 3' | 75 | 100 | 7bar |
| 3.5' | 90 | 100 | 7bar |
| 4' | 100 | 100 | 6bar |
| 4.5' | 110 | 100 | 6bar |
| 5' | 130 | 100 | 6bar |
PVC POLYMERSl FLAT HOSE(ULTRA-HIGH PRESSURE)
Environmentally friendly PP material: Adopting a new type of environmentally friendly PP material that meets the national EO level standard, it is safe and environmentally friendly Advanced process anti-aging: it is made by special process, and anti-aging ingredients are added to improve service life Wear resistant, sun resistant, frost resistant, and explosion-proof: resistant to high pressure at the moment of start-up, conducive to achieving explosion-proof effect, with a high safety factor for use.
| Size(inch) | Inner Diameter (mm) | Meters roll (m) | Pressure(B.P bar) |
| 2' | 50 | 60 | 15bar |
| 2.5' | 63 | 60 | 15bar |
| 3' | 75 | 60 | 13bar |
| 3.5' | 90 | 60 | 12bar |
| 4' | 100 | 60 | 12bar |
| 4.5' | 110 | 60 | 12bar |
PVC COATED FLAT HOSE(HIGE PRESSURE)
Coated PVC material preferred double-layer polyester thread: using PVC double-sided coating with polyester thread greatly increases product pressure resistance Wear resistant, sun resistant, frost resistant, explosion-proof: wear-resistant, thickened, finely crafted, does not harden in low temperature environments, and can be used normally in cold/hot areas
| Size(inch) | Inner Diameter (mm) | Meters roll (m) | Pressure(B.P bar) |
| 2' | 50 | 60 | 13bar |
| 2.5' | 63 | 60 | 13bar |
| 3' | 75 | 60 | 12bar |
| 3.5' | 90 | 60 | 10bar |
| 4' | 100 | 60 | 10bar |
| 4.5' | 110 | 60 | 10bar |
| 5' | 130 | 60 | 10bar |
All models support customization
