Detailed Description and Specifications
Width (mm) | Dia. (mm) | Wall thick (mm) | Holes qty/set | Hole set spacing (cm) | Flow rate (m³/hr/10 m) | Max. running length (m) | Spray range at two sides | Working pressure (bar) | Roll length (m) | Carton size (cm) |
32 | 20 | 0.2 | 2/3/5/7/9 | 10-40 | 0.7 | 20 | 1.25m each side | 0.2-0.8 | 200 | 363624 |
40 | 25 | 0.2 | 2/3/5/7/9 | 10-40 | 0.9 | 25 | 1.5m each side | 0.2-0.8 | 200 | 363628 |
50 | 32 | 0.2 | 2/3/5/7/9 | 10-40 | 1.55 | 50 | 2m each side | 0.2-0.8 | 200 | 363633 |
63 | 40 | 0.2 | 2/3/5/7/9 | 10-40 | 1.6 | 60 | 2.5m each side | 0.2-0.8 | 200 | 363633 |
63 | 40 | 0.3 | 2/3/5/7/9 | 10-40 | 1.6 | 60 | 2.5m each side | 0.2-0.8 | 100 | 333336 |
80 | 50 | 0.3 | 2/3/5/7/9 | 10-40 | 2.2 | 80 | 4m each side | 0.2-0.8 | 120 | 363635 |
100 | 63 | 0.3 | 2/3/5/7/9 | 10-40 | 3.1 | 100 | 5m each side | 0.2-0.8 | 120 | 363635 |
Double holes, inclined three holes, inclined five holes, inclined seven holes
Diameter (mm) | Diameter (mm) | Wall thickness (mm) | Wall thickness (mm) |
28 | 45 | 0.2, 0.3 | 25-4.0 |
40 | 50 | 0.2, 0.3, 0.35 | 15-4.0 |
50 | 63 | 0.35, 0.4 | 15-5.0 |
63 | 80 | 0.4, 0.5, 0.6 | 5.5-8.0 |
75 | 100 | 0.4, 0.5, 0.6 | 6.5-9.0 |
90 | 120 | 0.6 | 7.5-10.0 |
Product characteristics
1. The product is produced by double-layer co-extrusion process, smooth and even hole, no blind hole, anti-blocking performance is good.
2. The tube body is smooth without foreign point, light-resistant and anti-aging, long service life in the open air.
3. Equal pipe layout design, water spray effect is uniform and uniform.
4.Easy to install, operation is good, low price, one-time investment can be used repeatedly.
Conditions of Application
1. For greenhouse, greenhouse crops, reduce pests and diseases, save fertilizer and pesticides, improve economic efficiency.
2. For orchard irrigation it can effectively increase yield, improve fruit quality, and effectively control weed growth.
3. Suitable for cotton, flowers, herbal medicine, watermelon, field vegetables and other field crops, improve the efficiency of planting.
Points to Note
1. The water source must be clean and free of sundries. When necessary, the pump feed water should be wrapped over 60 mesh filter to prevent sundries from blocking the hole.
2. The best installation is to use more than two flow valves, depending on the pressure of the regulation band valve, so as to ensure the smoothness of the water flow.
3. If the hillside needs to be laid around the slope, not up and down, so as not to cause uneven pressure paper damage.
4. The hose should be laid as far as possible to avoid dragging, so as not to scratch the tube body.
